Name: Ajax Hub 2 Plus White - advanced control panel with alarm photo verification support 2xSIM, 4G/3G/2G, IP, Wi-Fi
Availability: InStock

Hub 2 Plus Jeweller

Control panel with Jeweller and Wings support (2 × SIM 2G/3G/LTE, Wi-Fi, Ethernet)

Capacity

Wireless Ajax devices

up to 200

Specifically, up to 10 sirens or keypads with a built-in siren and 5 range extender.

IP cameras or DVRs

up to 100

Seamless integration with Dahua,
Hikvision, Safire, EZVIZ, IP cameras, and DVRs,
RTSP support.

Users

up to 200

Any number of admin users within the hub limit.
PRO accounts for installers.
PRO accounts for installation and monitoring companies.
Access management for users.

Automation scenarios

up to 64

Alarm responses.
Scheduled actions.
Security mode changing reactions.
Temperature changing reactions.
Humidity changing reactions.
Reactions to changes in CO₂ concentration.
Reactions to pressing Button.

Security groups

up to 25

Rooms

up to 50

Wireless communication

Jeweller communication technology

Proprietary wireless communication technology to transmit alarms and events.

Key features:

Two-way communication.
Advanced anti-sabotage.
Block encryption featuring a dynamic key.
Instant notifications.
Remote configuration via the Ajax apps

Frequency bands

866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz

Depends on the sales region.

Maximum effective radiated power (ERP)

up to 20 mW

Featured automatic power control to reduce power consumption and noise interference.

Radio signal modulation

GFSK

Radio signal range

up to 2,000 m

Between the hub and connected devices (in an open space).
Maximum range depends on the connected device.

Polling interval

from 12 to 300 s

Adjusted by PRO or user with admin rights in the Ajax apps.

Encrypted communication

All the data stored and transmitted are protected by block encryption with a dynamic key.

Frequency hopping

To prevent radio interference and radio signal interception.

Wings communication technology

Proprietary wireless communication technology to transmit photo verifications.

Key features:

Two-way communication.
Block encryption featuring a dynamic key.
Advanced anti-sabotage.
Package re-uploading in case of transmission errors.
Photo delivery check.

Frequency bands

866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz

Depends on the sales region.

Maximum effective radiated power (ERP)

up to 20 mW

Featured automatic power control to reduce power consumption and noise interference.

Radio signal range

up to 1,700 m

Between the hub and connected devices (in an open space).
Maximum range depends on the connected device.

Encrypted communication

All the data stored and transmitted are protected by block encryption with a dynamic key.

Frequency hopping

To prevent radio interference and radio signal interception.

* Recommendations: The device operating voltage is 110–240 V~. Hub is designed for indoor installation only.

Communication channels

Ethernet

1 8P8C socket

Up to 100 Mbps.

Cellular

2 micro-SIM slots

Cellular bands

GSM900/DCS1800 (B3/B8)

WCDMA 850/900/2100 (B1/B5/B8)

4G (LTE)

FDD B1/B3/B5/B7/B8/B20

Wi-Fi

802.11 b/g/n module

up to 600 Mbps.

Automatic switching between communication channels

Instant switching between Ethernet, Wi-Fi and SIM.
Instant switching between 4G (LTE), 3G, and 2G networks of one SIM.
Switching between SIMs takes up to 4 minutes.

Communication channels prioritization

1. Ethernet
2. Wi-Fi
3. Cellular connection

Communication channels work in parallel to increase the system’s reliability.
Most of the data is transmitted via Ethernet.

Notifications

Supported notification types

Push
SMS
Calls

Event types

Alarms
Malfunctions
Security mode changing
System events
Non-security alerts
Automation devicesʼ events

The notification types are configured individually for each user.

Photo verification

Photo verification types

Photo by alarm
Photo by scenario
Photo on demand
Photo by schedule

The Photo by Schedule feature is available for hubs with firmware version OS Malevich 2.19 or higher.

Photo delivery time

up to 9 s

by default.

Photo resolution

up to 640 × 480 pixels

Depends on the detector.

Number of photos in a series

from 1 to 5 pictures

Monitoring

Supported protocols

SIA (DC-09)
SurGard (Contact ID)
ADEMCO 685
Other proprietary protocols

Event types

System alarms and events
Panic button coordinates
Photo verification

Power supply

Main

110–240 V~, 50/60 Hz

Up to 10 W of mains power consumption.

Backup

Built-in backup battery: Li-ion 3 А·h

Up to 15 hours of offline operation when Ethernet is disconnected.

Alternative

6 V⎓

Requires the 6V PSU for Hub 2/Hub 2 Plus/ReX 2 alternative power supply unit; sold separately.

Anti-sabotage

Tamper alarm

The system receives notifications about attempts to detach the device from the surface or remove it from the mounting panel.

Protection against spoofing

devices’ authentication

Proprietary authentication algorithms make it impossible to spoof the hub or connected devices.

Frequency hopping

The users and the security company receive notifications in case
of jamming or when the hub loses connection with the devices.

Enclosure

Dimensions

163 × 163 × 36 mm

Weight

351 g

Operating temperature range

from −10°C to +40°C

Operating humidity

up to 75%

Protection class

IP20

Complete set

Hub 2 Plus Jeweller

SmartBracket mounting panel

Power cable

Ethernet cable

Installation kit

SIM card (depends on the sales region)

Quick start guide
